| Item | Capabilities | |||
| Number of Layers | Single /Double Sided - 12 Layers | |||
| Major Material | FR-4, CEM-3, Hologen free, High
Tg (Other material as request) |
|||
| Min. Board Thickness | Double Side | 0.2mm (7.8mil) | ||
| 4 Layers | 0.4mm (16 mil) | |||
| 6 Layers | 0.6mm (24 mil) | |||
| 8 Layers | 1.0mm (40 mil) | |||
| 10 Layers | 1.2mm (48 mil) | |||
| 12 Layers | 1.5mm (59 mil) | |||
| Max. Board Thickness | 3.2mm (125 mil) | |||
| Surface Finishing | -Flash Gold Plating | |||
| -Immersion Gold (Max. 0.5¦Ìm) | ||||
| -Thick Gold Plating (Max. 1.5¦Ìm) | ||||
| -HASL (Tin / Lead) | ||||
|
-Entek Coating (OSP) - Gold finger |
||||
| -HASL - Lead Free | ||||
| -Immersion Tin | ||||
| Solder Mask | LPI (Wet Film), Thermal Cured Type | |||
| Other Printing | Carbon Print, Peelable Solder Mask | |||
| Solder Mask Plugged Hole | ||||
| Copper Thickness (Finishing) | 1/2 oz (18 ¦Ìm) - 4 oz (140 ¦Ìm) | |||
| Min. Hole Size | 0.25mm (10 mil) | |||
| Hole Size Tolerance (NPTH) | +/-0.05mm (2 mil) | |||
| Hole Size Tolerance (PTH) | +/-0.076mm (3 mil) | |||
| Min. Line Width and Spacing | 0.1mm (4 mil) | |||
| Min. Solder Mask Clearance | 0.076mm (3mil) | |||
| Min. Annular Ring | 0.076mm (3mil) | |||
| Profile and V-Cut | V-Cut, Jump V-Cut, CNC V-Cut | |||
| CNC-Routing, Stamping and Beveling | ||||
| Special Process | Blind/Buried Via Hole | |||
|
If you have any special requirments,we can do for you! |
||||
